TIMTEL THERMALLY CONDUCTIVE ADHESIVE FILMS
THERMALLY CONDUCTIVE ADHESIVE FILMS
Adhesive Film (unsupported)
FastelTack T20
Type: Pressure Sensitive AdhesiveSubstrate: none (unsupported)Thickness: 0.051mm
Single or Double Coated Foil (non-dielectric substrate)
T20-AL
Type: Pressure Sensitive AdhesiveSubstrate: Aluminum Foil
Orientation: Single or Double Sided
Thickness: 0.076mm to 0.23mm
T20-CU
Type: Pressure Sensitive AdhesiveSubstrate: Copper FoilOrientation: Single or Double SidedThickness: 0.076mm to 0.23mm
T20-GF
Type: Pressure Sensitive AdhesiveSubstrate: Graphenol HSOrientation: Single or Double SidedThickness: 0.082mm to 0.14mm
Single or Double Coated Film (dielectric substrate)
T20-KP
Type: Pressure Sensitive AdhesiveSubstrate: Kapton MT+ (plus)Orientation: Single or Double SidedThickness: 0.089mm to 0.15mm
T20-K
Type: Pressure Sensitive AdhesiveSubstrate: Kapton MTOrientation: Single or Double SidedThickness: 0.076mm to 0.18mm
Request Sample or Technical Data Sheet
